| Paper Types |
Offset Paper, Coated paper |
| Feeding Method |
Automatic Air Suction Feed |
| Operating Speed |
5 Adjustable Levels |
| Operation Interface |
7-inch Color LCD Touch Screen |
| Machine Design |
Floor-standing |
| Counting Method |
Forward / Reverse Counting |
| Job Memory (Data Storage) |
32 Groups |
| Max Input Paper Size |
950×330mm |
| Min Input Paper Size |
135×135mm (Optional 45×90mm) |
| Paper Weight (Creasing) |
125g-400g |
| Paper Weight (Perforating) |
125g-300g |
| Feed Tray Capacity |
90mm |
| Extended Feed Table |
Optional |
| Delivery Tray Capacity |
120mm |
| Numbering Direction |
Forward and Reverse Optional |
| Crease Width/Gap |
0.9mm (Optional 0.6mm) |
| Crease Direction |
Positive and Negative (Up/Down) |
| Precision |
±0.2mm |
| First Crease Distance (from head) |
1mm |
| Creasing Speed |
8500 sheets/hour (A4 single crease) / 145 sheets/min |
| Max Operations per Sheet |
32 lines (Creases/Perforations) |
| Power Supply |
220V / 50Hz |
| Power Consumption |
600 W |
| Net Weight |
120 kg |
| Machine Dimensions |
620×1660×1070mm |
